Switch Type

• Smart

Switch Ports

• 5-10

Jumbo Frame (FE, GE)

• 9K

LEDs

• System (blue), Link/Act (green)

VLAN

• Port-based and 802.1q tag-based VLANs, Management VLAN, Guest VLAN support, Dynamic VLAN assignment via Radius server with 802.1x client authentication

Memory

• 128MB

Forwarding Rate

• 11.90 Mpps

Dimensions (LxWxH)

• 210 x 104 x 25 mm (8.3 x 4.1 x 1.0 in.)

Weight

• 0.528 kg (1.16 Ibs.)

System Power Consumption without PoE+

• 110V:7.94W
• 220V:7.93W

Number of VLANs Supported

• 128 active VLANs (4,096 range)

Operating Humidity

• 10 to 90% RH

Operating Temperature

• 0 to 50°C (32 to 122°F)

Security Features

• 802.1x Radius authentication
• DHCP snooping
• IP-MAC binding
• Management access control
• Port security supports limited dynamic lock and locked MAC address

Power Input

• (0.5A max)
• 100-240V
• 50-60Hz

Spanning Tree

• IEEE 802.1d Spanning Tree, IEEE 802.1s Multiple Spanning Tree, IEEE 802.1w Rapid Spanning Tree

Storage Temperature

• -40 to 70°C (-40 to 158°F)

RMON

• Embedded remote monitoring (RMON) software agent support for enhanced traffic management, monitoring, and analysis

Total System Ports

• 8GE

Switching Capacity

• 16 Gbps

HOL Blocking Prevention

• Head-of-line (HOL) blocking prevention

Auto Voice VLAN

• VLAN Voice traffic is automatically assigned by OUI to a voice-specific VLAN and treated with appropriate levels

Other Management

• Telnet (Menu CLI), DHCP client, system log, configuration unload and backup via HTTP or TFTP, PING, dual images, SNTP

Link Aggregation

• IEEE 802.3ad LACP, up to 4 groups with up to 8 ports per group

Storm Control

• Broadcast, flooding, and multicast

Management Interface

• HTTP
• HTTPS

QoS - Scheduling

• Priority queuing and weighted round robin (WRR)

SNMP

• Version 1
• Version 2c

QoS - Class of Service

• Port-based, 802.1p priority-based, IPv4/v6 IP DSCP-based

Storage Humidity

• 10 to 90% RH (non-condensing)

Green Power Mode

• EEE+, Short Reach + Energy Detect

IGMP Snooping

• IGMP (v1/v2/v3) snooping provides for fast client joins and leaves of multicast streams and limits bandwidth-intensive video traffic to only the requestors; supports 256 multicast groups

Network Standards

• IEEE 802.1d
• IEEE 802.1Q/p
• IEEE 802.1X
• IEEE 802.3
• IEEE 802.3ab
• IEEE 802.3ad
• IEEE 802.3az
• IEEE 802.3u
• IEEE 802.3x
• IEEE 802.3z

Port Mirroring

• Traffic on multiple ports (up to four ports) can be mirrored to another port for analysis with a network analyzer

Firmware Upgrade

• TFTP
• Web Browser (HTTP/HTTPS)

QoS - Priority Levels

• 4 hardware queues

Copper FE/GE Ports (RJ45)

• g1-g8
